Solar Panels > Luminous Polycrystalline Solar PV Module 170Wp 12V
The Lumonius 170Wp Polycrystalline Solar Panel is a reliable and efficient workhorse, designed to convert sunlight into clean, usable energy for your home or business. Crafted with high-quality polycrystalline cells, this panel delivers exceptional performance at an attractive price point.
Generating a maximum power output of 170 watts, the Lumonius 170Wp panel is perfect for a variety of applications, from powering small off-grid systems to supplementing your existing grid-tied setup. Its 12-volt DC output seamlessly integrates with most solar charge controllers and inverters, ensuring a smooth and efficient energy flow.
| ★ | Compliance to IEC standards. |
| ★ | Best in Class conversion efficiency. |
| ★ | Anti-reflective coating and back surface (BSF) for more light absorption. |
| ★ | Advanced EVA (ethyl vinyl acetate) encapsulation to give better protection to modules. |
| ★ | High strength light-weight aluminum frame design for high torsion resistance against winds and snow loads. |
| ★ | PID resistance Technology (Potential-Induced Degradation) for safety against substantial power loss due to stray currents triggered by certain climate conditions. |
| ★ | Excellent Low light performance in low visibility in clouds, evening, and morning. |
| Nominal Maximum Power (Pm) | 170Watts |
| Open Circuit Voltage (Voc) | 23.01V |
| Short Circuit Current (Isc) | 9.61A |
| Voltage at Maximum Power (Vmp) | 18.86V |
| Current at Maximum Power (Imp) | 9.02A |
| Dimensions (LxWxT) - CM | 150.5 x 68.6 x 3.5 |
| Solar Cells per Module (Units) / Arrangement | 48 |
| Warranty | 60 months. |
| Warranty Policy | If the product is broken/damaged it will not be covered in the warranty. Click Here for Luminous Warranty Statement. |
| Disclaimer | We strive for accurate warranty information, but manufacturers may update terms. Please visit their website for the latest details. |
